Servo proportional electromagnet

locationHome > Products > Servo proportional electromagnet
Servo proportional electromagnet GP61D4-A IW
Servo proportional electromagnet GP61D4-A IW
Servo proportional electromagnet GP61D4-A IW
model GP61D4-AIW
Specifications Φ60mm
trip  4+5mm
Rated suction 180N
coil R2.55Ω IN3.7A
Enclosure protection class IP65
Email aykd_scb@126.com
Tel +86-372-2595077/2595078/2595088
Description
This series of products are used in the electro-hydraulic proportional closed-loop control system, which is matched with the electro-hydraulic proportional control amplifier. The measuring head of LVDT linear displacement sensor on the electromagnet is rigidly connected with the armature, which can realize the direct detection of the valve core position, so as to achieve the purpose of accurately controlling the valve core position。
Parameters

Main technical parameters:

model

GP61D4-AIW

Specifications

Φ60mm

trip

4+5mm

Rated suction

180N

coil

R2.55Ω  IN3.7A

Enclosure protection class

IP65
