Servo proportional electromagnet GP63-S-* IW63 series
Servo proportional electromagnet GP63-S-* IW63 series
Servo proportional electromagnet GP63-S-* IW63 series
model GP63-S-BIW63/ GP63-S-CIW63
Specifications Φ63mm
trip 4+5mm
Rated suction 150~170N
Oil pressure resistance 21MPa
Enclosure protection class IP65
Email aykd_scb@126.com
Tel +86-372-2595077/2595078/2595088
Description
This series of products are used in the electro-hydraulic proportional closed-loop control system, which is matched with the electro-hydraulic proportional control amplifier. The measuring head of LVDT linear displacement sensor on the electromagnet is rigidly connected with the armature, which can realize the direct detection of the valve core position, so as to achieve the purpose of accurately controlling the valve core position。
Parameters

Main technical parameters:

model

GP63-S-BIW63/GP63-S-CIW63

Specifications

Φ63mm

trip

4+5mm

Rated suction

150N-170N

Oil pressure resistance

21MPa

Enclosure protection class  IP65
